GIN | GTO 3

Product Details

GTO 3

Sports competition
EN C

OUR SPORTS RACER

The GTO 3 is a serious XC wing aimed at competitive sports class (EN C) pilots. All aspects of performance have been optimised, from glide performance, top speed, B riser pressure to handling and feedback. The wing helps you develop that uncanny knack of climbing to the top of the gaggle and maximising this advantage on glide.

Technical Specifications

Size	XXS	XS	S	M	L	XL
Flat area (m2)	19.75	21.2	22.77	24.39	26.1	27.9
Flat span (m)	11.24	11.7	12.13	12.5	12.87	13.32
Flat aspect ratio	6.5	6.5	6.5	6.5	6.5	6.5
Projected area (m2)	16.49	17.84	19.21	20.38	21.62	23.16
Projected span (m)	9.04	9.4	9.75	10.05	10.35	10.71
Projected aspect ratio	4.95	4.95	4.95	4.95	4.95	4.95
Chord (m)	2.13	2.22	2.3	2.37	2.44	2.52
Number of cells	71	71	71	71	71	71
Glider weight (kg)	3.86	4.1	4.3	4.46	4.7	4.9
Weight range (kg)	60 - 75	70 - 85	80 - 95	90 - 105	100 - 115	110 - 130
Certification	EN C	EN C	EN C	EN C	EN C	EN C

Performance and stability

The new profile of the GTO 3 enables even more pitch stability, especially when on bar. The glide feels very floaty as the wing has a tendency to efficiently cut through the air. All this equates to better performance.

Handling and climbing

The intuitive turn of the GTO 3 is guaranteed to put a smile on your face. Handling is precise and direct and the wing requires minimal management in thermals, allowing you to focus on your strategy. The new planform with the swept back wing shape, in conjunction with the Wave Leading Edge, makes for exceptional climbing performance and feel.

Long usable speed range

The GTO 3 has a long accelerator travel with optimised B riser pressure. The stability at full speed is high, giving you full usability of the entire speed range.

Nature`s technology built-in

The GTO 3 features our Wave Leading Edge technology, which increases the performance at high angles of attack, giving a better sink rate at low speeds along with a more delayed and progressive stall. Inspired by the tubercles of the humpback whale, the technology has been realised in paragliders through the “GIN LAB”, a wind tunnel project run by Gin Gliders in collaboration with Ulsan National Institute of Science and Technology in South Korea.

Gallery

Details

Wave Leading Edge Technology (WLE) for increased performance at high angles of attack
2 risers for true rear riser steering
Speed system with 20mm Allen pulleys
Plastic rods for enhanced rigidity and structural support
Semi light construction with 29g fabric on top and bottom surface
Unsheathed aramid lines with optimised diameters
17cm speed range for top of the ranfe top speed

Riser details

12 mm Cousin Kevlar
Ergonomic break handles
Optimized B control bar
A3 stopper
Brummel hooks
High quality 20mm Allen pulleys
Color codificated attachment point
Color codificated lines

Materials

Canopy cloth

Upper surface leading edge: Dominico 30DMF 41g²

Upper surface: Myungjin, MJ29MF 29g²

Lower surface: Myungjin, MJ29MF 29g²

Lines

Upper: Edelrid 9200-035 8001-050 | 070 | 090 (Aramid - Dyneema)

Middle: Edelrid 9200-035 8001-050 | 070 | 090 8001-130 (Aramid)

Main: Edelrid | Gin 8001-050 | 070 | 190 | 340 (Aramid) TGL 220 (Aramid)

Colours

Included with your glider

Light concertina bag

GIN stickers

Repair kit

Documents

EN test report

Manual
